National Building Code Standards for Fire and Smoke Damper Installation
Understanding the rigorous safety standards set by the National Building Code of Canada (NBC) is essential for any commercial building project. At empcontracting.ca Inc. your construction contractor in London, Ontario, we prioritize compliance and safety, ensuring every HVAC and fire protection system meets the latest regulatory requirements.
When Smoke Dampers May Be Waived (NBC 3.1.8.9)
While smoke dampers are critical for life safety, Clause 3.1.8.9 provides specific exemptions where smoke dampers or combination fire/smoke dampers may be waived. These exceptions are typically permitted for:
- Commercial Cooking: Ducts serving commercial cooking equipment compliant with Article 6.3.1.6.
- Single Fire Compartments: Duct systems where all inlets and outlets serve only one fire compartment.
- Vertical Fire Separations: Systems with continuous air movement and configurations that prevent the recirculation of exhaust or return air during fire emergencies.
Exemptions for Noncombustible Branch Ducts
Dampers may also be waived for noncombustible branch ducts with a melting point above 760°C, provided they have a cross-sectional area not exceeding 0.013 m² or are designed to function as part of a dedicated smoke control system.
Installation Protocols for Fire Dampers (NBC 3.1.8.10)
The reliability of a fire damper depends entirely on its installation. As empcontracting.ca Inc. your construction contractor in London, Ontario, we ensure that fire dampers are installed to remain in place even if the ductwork fails during a fire event.
Automatic Closure and Temperature Ratings
Fire dampers must be configured to close automatically via a fusible link or other heat/smoke-actuated devices. Key requirements include:
- Thermal Sensitivity: Heat-actuated devices must be located where they are readily affected by temperature rises in the duct.
- Temperature Rating: The device must be rated approximately 30°C above the maximum temperature of the system during normal operation or shutdown.
- Testing Orientation: Dampers must be installed in the specific vertical or horizontal position for which they were tested.
Furthermore, a tightly fitted access door is mandatory for each damper to allow for regular inspection and resetting of the release mechanism.
Installation Standards for Smoke Dampers (NBC 3.1.8.11)
Smoke dampers serve as the primary defense against the spread of toxic fumes within a building. The NBC requires specific placement for these units:
Placement in Fire Separations
Where smoke dampers are used in air-transfer openings, they must be installed directly in the plane of the fire separation. For combination smoke/fire dampers used within a duct, they must be installed within 610 mm of the plane of the fire separation, ensuring there are no inlet or outlet openings between the separation and the damper.
