Understanding the seismic requirements for glazing systems is essential for modern construction. Under section 4.1.8.18 of the 2024 Ontario Building Code (OBC), specific calculations must be followed to ensure glass retention during seismic events.
Glass Fallout and Relative Displacement Requirements
According to Sentence (14), the relative displacement at which glass fallout occurs (Dfallout) must be the greater of 13 mm or 1.25 times the design earthquake displacement (IEDp). This ensures that glazing systems can accommodate structural shifts without posing a safety hazard to occupants or pedestrians.
Conditions for Exemption from Standard Displacement Rules
Sentence (15) provides specific scenarios where standard displacement rules may be waived, provided specific safety criteria are met:
- Seismic Category: Buildings within SC1 or SC2 categories.
- Frame Clearance: When the clearance between the glass and the frame (Dclear) is at least 1.25 times the calculated displacement (Dp).
- Safety Glass Height: Fully tempered, monolithic glass in non-post-disaster buildings, provided it is no more than 3 m above a walking surface.
- Laminated Glass Specifications: Annealed or heat-strengthened laminated glass with a minimum interlayer of 0.76 mm, mechanically captured and secured with a 13 mm minimum elastomeric sealant bead.
Supplemental Energy Dissipation and Lateral Force
For advanced structures utilizing supplemental energy dissipation, Sentence (16) dictates that components must be designed for a specified lateral earthquake force (Vp).
Calculating Lateral Earthquake Force (Vp)
The formula for determining lateral force incorporates the peak spectral acceleration (Ssed) and the importance factor of the building (IE). This calculation ensures that the connections between the structure and its architectural components remain secure during high-period seismic oscillations.
